1 BAR LIFTING BAGS
TECHNICAL DETAILS
AK
LB0019/003
61 / 24”
43 / 17”
5 / 2”
66 ø x 20 / 26 ø x 8”
2976 / 6561
1 / 14.5
295 / 10.4
15 / 33
30 / 66
BK CK
LB0020/003 LB0021/003
Neoprene Coated Kevlar
DK
LB0022/003
122 / 48”
100 / 39”
10 / 4”
122 ø x 22 / 48 ø x 9”
11902 / 26239
1 / 14.5
3010 / 106.3
25 / 55
50 / 110
Product Code
Materials
Diameter (cm / inch)
Inflated Height (cm /
Deflated Height (cm
Packed Size Diameter ø x Height
Lift at Max Pressure
Max. Pressure (bar /
Air Requirements (ltr
inch)
/ inch)
(cm / inch)
(kg / lbs)
psi)
/ ft3)
76 / 30”
59 / 23”
5 / 2”
77 ø x 20 / 30 ø x 8”
4650 / 10251
1 / 14.5
620 / 21.9
17 / 37
34 / 75
b
91 / 36”
61 / 24”
5 / 2”
96 ø x 20 / 38 ø x 8”
6694 / 14758
1 / 14.5
900 / 31.8
23 / 50
45 / 99
Packed Weight - One Bag (kg / lbs)
Packed Weight - Two Bag (kg)
SYSTEM SCHEMATIC
a 123
Low-Pressure Supply
Either from BA cylinder & 8 bar regulator or a compressor set between 1 & 3 bar (7.3 and 44 psi)
123
c
4
4
BA Cylinder (By others)
a
Regulator, 8 bar (116 psi)
(Regulator only: RE0034, Regulator & hose: RE0034/004)
Aluminium Double Control Unit - 1 bar (CO0130)
1 bar Low Pressure Lifting Bags x2 (see table above)
b
c
Option:
Yellow Inlet Hose [T26M - T.26M] (2m: HS-01-04-02-06-06 5m: HS-01-04-05-06-06 10m: HS-01-04-10-06-06)
: www.mfc-international.com : +44 (0)1443 433 075
Green Outlet Hose [GEKA] (5m: HS-02-02-05-13-13 10m: HS-02-02-10-13-13)
Red Outlet Hose [GEKA] (5m: HS-02-01-05-13-13 10m: HS-02-01-10-13-13)
Shut-off Hose [GEKA] (LB9034)
