0.5 BAR LIFTING BAGS
TECHNICAL DETAILS
Product Code
Materials
Diameter (cm / inch)
Inflated Height (cm / inch)
Deflated Height (cm / inch)
Packed Size
Diameter ø x Height (cm / inch)
Max. Pressure (bar / psi)
Lift at Max Pressure (kg / lbs)
Air Requirements (ltr / ft3)
Packed Weight (two cushions) (kg)
SYSTEM SCHEMATIC
A
LB0015
61 / 24”
43 / 17”
5 / 2”
66 ø x 20 / 26 ø x 8”
0.5 / 7
1488 / 3280
222 / 8
30 / 66
B C
LB0016 LB0017
Hypalon Coated Nylon
D
LB0018
122 / 48”
100 / 39”
10 / 4”
122 ø x 22 / 48 ø x 9”
0.5 / 7
5951 / 13120
1900 / 67
50 / 110
76 / 30”
59 / 23”
5 / 2”
77 ø x 20 / 30 ø x 8”
0.5 / 7
2325 / 5125
450 / 16
34 / 75
b
91 / 36”
61 / 24”
5 / 2”
96 ø x 20 / 38 ø x 8”
0.5 / 7
3347 / 7379
673 / 24
45 / 99
a 123
Low-Pressure Supply
Either from BA cylinder & 8 bar regulator or a compressor set between 0.5 & 3 bar (7.3 and 44 psi)
c
4
1234
BA Cylinder (By others)
a
Regulator, 8 bar (116 psi)
(Regulator only: RE0034, Regulator & hose: RE0034/004)
Aluminium Double Control Unit - 1 bar* (CO0130)
0.5 bar Low Pressure Lifting Bags x2 (see table above)
b
c
Option:
Yellow Inlet Hose [T26M - T.26M] (2m: HS-01-04-02-06-06 5m: HS-01-04-05-06-06 10m: HS-01-04-10-06-06)
Green Outlet Hose [GEKA] (5m: HS-02-02-05-13-13 10m: HS-02-02-10-13-13)
Red Outlet Hose [GEKA] (5m: HS-02-01-05-13-13 10m: HS-02-01-10-13-13)
Shut-off Hose [GEKA] (LB9034)
*1 bar (14.5 psi) Controllers can be used safely as bags are fitted with a 0.5 bar pressure release valve
